Xhorse VVDI BGA MB TOOL User Feedback Collection

Xhorse VVDI MB BGA TOOL is welcomed as a professional key programmer for all Benz keys. Considering you may be interested in this tool’s real performance, here is Xhorse VVDI BGA MB tool user feedback collection for you reference.
  • VVDI BGA MB tool do all key lost, add key, renew ECU
  • VVDI MB TOOL read and calculate BGA password, make Benz keys
  • VVDI MB TOOL renew EIS/ESL
  • About VVDI BGA MB tool extra K-line cable
  • Other feedbacks
VVDI BGA MB tool do all key lost, add key, renew ECU
—I got my tool on Monday. So far I tried all key lost for:
3x W212 old —— worked
2x W166 ——- worked
3x W212 new ——- worked
2x W246 ——– worked
From BGA key
W212 old ——- worked
W212 new —— worked
Copy EIS:
W164 new —– worked
W164 old —– worked
W212 new —– worked
W204, W207 —— worked
— I try today to renew ECU ME9.7 with VVDI BGA MB tool…..successful. With 7G boxes works on hurray.
— Add key (20 minutes for one):
E300L…work fine
R500 4 matic…work fine
CLS260…work fine
S320…work fine
E260…work fine
W204 – 2011 – NEW KEY…work fine
— I tested it ok on both car type W203 (year 2003) and W639 (year 2006)
— I used my tool for reading BGA and be keys. It’s very good to renew 7G plates and ECU. And I also tested renew sim4se It is a W203 engine ECU with no screws… one ECU was working renew good other sim4se was reading ok.

VVDI BGA MB tool read and calculate BGA password, make Benz keys
—VVDI MB TOOL is the most fast tool for pass calculation for EZS FSB3 (w166 etc.)
— VVDI MB TOOL support read w164 via OBD without gateway, but you need special adapter to replace gateway as inter unit
— W203: EIS A203.545.05.08 – MCU 1J35D – read PSW – OK
W 220 EIS 215 545 02 08 read PSW via IR – OK. (This but not means all W215 can support. In fact only support parts of this type)
— I’ve been able to read Version 40, 51 and 57 until now with this device.
— Just extracted pass by IR on a W203 within 2 minutes. Wonderful!
— VVDI MB tool password calculation test:
Calculate 221EIS password… work fine
Calculate 212 545 03 08 password… work fine
—Xhorse engineers developed their own algorithm also they have special dedicated server for BGA calculation and FSB3 pass calculation. With VVDI MB TOOL only need at LEAST two calculations for BGA pass and for FSB3 is 100% ok! Other tools need more than 2 calculations. And VVDI server is the fastest at the moment much faster than others.
— I succeeded in making a spare key on a W211 yesterday. But I extracted the pass from the original v51 key and after that the remote function of the original key stopped working (it wasn’t emitting at all and the LED didn’t flash) and it wasn’t starting the car too. I had to renew and program it again to make it work. Finally I got the answer: sometime this happen when NEC is not right soldered back to PCB, or sometime this happen when NEC is not right soldered back to PCB.
— It works well, as Xhorse still have some little problem like dealer pass or erase password calculation but it only few little bugs that I hope they will fix soon.

VVDI BGA MB tool renew EIS/ESL
— I check W204 ESL and it damage, so I bought a second-hand ESL to work with my VVDI MB TOOL. I took steps as follows and it worked.
1 get key password
2 save EIS data with Pass
3 renew EIS
4 write saved EIS data
5 renew ELV
6 in EIS personalize ELV
7 Insert Key all should work
Also you can refer to these, I found from forum.
ESL: Clear TP, Renew ESL (need erase password)
EIS: Renew EIS (need password & erase password)
Write EIS data back, then Personalize W204ESL
(0ne token for read key code)
— Guys I picked it up from forum, share this solution with you all.
I tried to renew w210 EIS and got the key password and erase password, but once I click on renew EIS it says failed how can I renew EIS for Motorola w210?
You should ensure your password is correct then try again. Some types of old K line EIS cannot support renew.

About VVDI BGA MB tool extra K-line cable
— The extra K-line cable is for use for example with some type of older EZS/EIS, which have his diag PIN in OBD plug in different place then standard norm K-line…for example W203, W639….this models you can read through OBD cable only when you use this BLUE extra cable and connect it to other PIN, in case W203 and W639 have EZS/EIS on PIN nr.1 in car OBD plug…or for use on the table on bench then you can read EZS/EIS through cable too….not only by IR.

Other feedbacks
— A friend of mine received his VVDI MB tool , no manual no instruction , no drivers only machine…he managed to install it and in 7 minutes he made BGA key , he was shocked and I am also! For VVDI BGA my friend say is very good with BGA with older models he is not so sure.
— Xhorse support is 10000% ok and very helpful and is quick instantly. Of course need to synchronize time between your country and china and they have many flash and dumps for backup.

5/17/2017

Xhorse VVDI Key Tool Transponder Remote Key Programmer with 5 Remote Keys

Eobdtool.co.uk new released Xhorse VVDI Key Tool, it will replace CN900 Mini and handy baby key programmer, support most common remote types in the market. VVDI Transponder Key Programmer can edit transponder, clone transponder, test frequency, clone Remote, generate remote, generate garage door remote controller, unlock smart card etc. In a word, Xhorse VVDI Key Tool is a device with multi-functions.


Xhorse VVDI Key Tool Basic Information:
Language: English
Software Version: V1.2.8
Hardware/Firmware Version: 1.1



















VVDI Key Tool highlights:
1: Support transponder copying / clone, also support 4th 48 chip online
2: Identify almost transponder in market
3: Support re-programming almost transponder in market
4: New remote re-generating / new remote making


Xhorse VVDI Key Tool functions:
Transponder Generation:
Write most common transponder available in the market including 36, 46, 47, 60, 70

Transponder cloning:
Support 46 42 11 12 4D

Frequency & power tester:
Frequency test of 27-900 MHZ
Power test 300-450 MHZ

Remote cloning:
Rolling code & Fixed code

Generate remote:
More than 400 FCC ID types

Generate Garage door remote:
More than 100 types

Unlock OEM remotes:
NXP keyless & Prox Remotes

If you need more information, please check it here: http://www.eobdtool.co.uk/wholesale/vvdi-key-tool-86288.html

5/11/2017

Need Tokens for VVDI MB BGA Key Tool?

VVDI MB TOOL is the first Tool in the world that can calculate PASSWORD from Mercedes Benz BGA keys and Calculate Password For EZS by IR with ALL KEY LOST

Now support all key lost: w204, w207,W166, W246, W212, W212(old),some W216, W164 2009- future will add more

While some people may misunderstand VVDI MB Tool will charge tokens for each key calculation every time. In fact, it is not truth.

Tokens need only for BGA Keys or for car with Lost keys...
For BGA keys, it will charge one token, while for Lost keys, Two tokens.

BUT, if the car has V51 or V57 Key, and can be opened, simply remove Nec, place on the Nec chair, read password from Key then carry our key calculation.
All this will be free....

If you need tokens, you can check

VVDI2 MB Tool Benz BGA Password Calculation Token(33.99EUR)


If you need more, you can buy 5 tokens together to save money

It is very easy and fast to add the tokens to your VVDI Benz Tool, after your payment, you just need provide the serial number of your VVDI Benz tool, then we will add the tokens to your VVDI MB Tool

Xhorse V4.2.0 VVDI2 Key Programmer Newest Software Release

VVDI2 Key Programmer has been updated to newest version V4.2.0.New function released: Audi A6L, A7, A8L, Touareg lost all key. Here we provide you Newest VVDI 2 V4.2.0 Software Download link for free


VVDI2 V4.2.0 Software Download link
https://mega.nz/#!345DQSbB!yrwasF35hNneR2vwpCWubMDHHHbFPQcMs1P3a_baofc


Xhorse VVDI V4.2.0 Update Information:
*** 2017-05-11
*** Require firmware V4.2.0
************************************************** **********************
===== Note =====
1. Update firmware v4.2.0 require the latest online update tool v4.2.0 version
2. Please download latest install software first then update firmware

===== VAG V4.2.0 =====
1. New function released: Audi A6L, A7, A8L, Touareg lost all key:
(1). Support ECU with MED17/EDC17 type OR Gearbox with 8 speed CVT type
(2). Require BCM2 data, most of them can read with VVDI2 via OBDII
(3). Require ELV data, you can read with VVDI-PROG
(4). Switch ON igniton with OBDII operation, simple and safe
(5). Collect data from internal-can
(6). Fast calculate speed, only need 1 minute
(7). Freee for all customer with immo5 authorize, every success calculate require 100 remote points
2. Bugfix for immo5 keylearn
3. Bugfix for write A4/Q5/A5 KM
4. Bugfix for read pin and CS from ECU (SIMOS PPD1.1/1.5)
5. Bugfix for flash FRF file
6. Bugfix

===== BMW V4.2.0 =====
1. Bugfix

===== Porsche V4.2.0 =====
1. Bugfix

===== PSA V4.2.0 =====
1. Bugfix

===== Transponder Programmer V4.2.0 =====
1. Support Inida Mahindra special transponder ID46: Xylo, Scorpio
2. Immobilizer data tool: add new for Suzuki swift 2012- 93C86
3. Immobilizer data tool: bugfix for Opel IMMO-2 TMS
4. Immobilizer data tool: bugfix for Brilliance Zunchi 93C64
5. Immobilizer data tool: bugfix for Fiat Marea 93C46
6. Copy Transponder support the latest copy transponder(HITAG2)
7. Bugfix

===== J2534 V4.2.0 =====
1. Bugfix

===== Online Upate Tool V4.2.0 =====
1. Update firmware v4.2.0 require the latest online update tool v4.2.0 version
2. Please download latest install software first then update firmware

===== Quick Start V4.2.0 =====
1. Bugfix

Xhorse VVDI2 V4.1.1 Update Information
VAG V4.1.0
BMW V4.1.0
Porsche V4.1.0
PSA V4.1.0
Passthru J2534 V4.1.0
Online Update Tool V4.1.0
Quick Start V4.1.0

You can find the detail update information from Readme in newest software, Mainly include:
1. Add support to read PIN code from santana ECU (Special Function->Engine Control Unit)
2. Bugfix for write A4/Q5/A5 KM
3. Bugfix for OBD read key information from CAS (9389115): Now we dont support read this CAS ID via OBDII, will add soon

5/08/2017

VVDI MB Tool Power Adapter: 18 mins Data Acquisition on W204 W207 all key lost

The day when VVDI MB Tool Power Adapter was available, I paid €123.5 on one, yesterday it arrived me and I tested and verified it works as fine as it claims.

VVDl MB T00L Power adapter Pros (Xhorse claims and I verified working):
1. VVDI MB TOOL power adapter working on FBS3 type all key lost and gateway emulation, support C class, E class, CL, CLK. ML. GL. GLK types etc..
2. VVDI MB TOOL power adapter only needs 18 minutes for data acquisition on W204 W207 all key lost; without this adapter it will cost 150 minutes for data acquisition, save
  nearly 2 hours(150 minutes ->18 minutes)
3. VVDI MB TOOL power adapter for W216, W164 2009- all key lost data acquisition.no need to replug IR adapter many times; without this adapter need to replug IR adapter for 500 times, save a great deal of manpower{500 times->0 time)
4. VVDI MB TOOL power adapter support gateway emulation function, without real gateway you can use this adapter directly OBD communication with W164, W164 2009-, W209, W211 (require special connection cables)
5. VVDI MB TOOL power adapter will keep updating more functions

VVDl MB T00L Power adapter has to work with MB BGA tool, they a full set of MB BGA tool plus Power adapter.
How to connect MB BGA tool with the Power adapter?
here video demo VVDI MB Tool Power Adapter:


4/19/2017

Audi A6L all key lost new key made by VVDI2 and VVDI PROG

This blog will show you steps for VVDI2 Commander and VVDI PROG Key Programmer work together to make a new key for Audi A6L all key lost.
Step1. Open Audi A6L engine cover, find the engine and disassemble it. Remove the engine ECU.

Warm up the ECU edge to open ECU safely, find the 95320 chip as below, desolder the chip and put it on VVDI PROG to read data.

Step2. Open VVDI PROG software, choose correct “Type”, “Brand” and “Chip” at right side. Click “New” and “Read” then “Save” to save the bin file. Remove the chip 95320 from VVDI PROG, solder it back to engine ECU and reinstall ECU to Audi A6L.
Step3. Open Xhorse VVDI2 software and choose “Audi” option. Click “Special Function” on top menu bar. Then click “EEPROM Data Processing Tool”. First you need to calculate the CS code: choose “EEPROM Simons PPDIx- Reset component protection data”.

Step4. Click “Read” and load the bin file that is read out just now, click “Open”. And you can see the CS code as picture, record it with your camera or pen.

Next is to calculate the PIN code. Back to “EEPROM Data Processing Tool” dropdown menu and choose “EEPROM Simons PPDIx- Security Access Code”. Click “Read” and load the bin file, PIN code is read out. Record the code.

Step5. Back to Xhorse VVDI2 software main menu; choose “Key Learning” and “Audi A6/A7” option. Input the CS code and PIN code then you can see the buttons “Learning Key” and “Generate Dealer Key” are working.
Put a new remote key chip into VVDI2 coil. Click “Generate Dealer Key” and it will show success soon.
Step6. This step is going to learn key. Disconnect the short insurance line and connect it again.

Now take out the remote chip and put it close to car’s ignition data coil. Open and close the car door. Turn on ignition and press down brake. Click “Learning Key” and you can see learning success.
Step7. This is the last step: read out EZS-EEPROM (J518) EEPROM to generate the OEM remote control.
Choose chip type “9S1201128” then save EZS-EEPROM (J518) EEPROM file. And start to generate the OEM remote control.
Choose the EEPROM file to open then put the remote control vertically into VVDI2 coil. Click “Open” and “Next”.

The OEM remote control is generated successfully! Assemble it to the new key and test. Now Xhorse VVDI PROG Programmer and VVDI2 Tool together make a new key successfully for Audi A6L all key lost! The car will start and the remote function will work!

How to build EIS/ELV NEC adapter for VVDI MB Tool

HaveEIS/ELVcable tester for your vvdi mb tool? Think it expensive? You can make EIS/ELV NEC adapter by yourself and save a lot.


For Mercedes W204 W212 W221 W164 W166, its necessary to have this adapter to use with the EIS ELV maintenance, Mercedes key programming and key detection.

Here are somediagrams for reference.
W164 / R251 / W221 / W216 with NEC inside
w203 / vito w639 with mcu HC908 inside
w203 with mcu hc912 inside

W204 / W207 / W212 with NEC inside

W210 / W208 / W202 with HC705 iside

W211 / W219 / W209 with HC912 inside

W220 / W215 / R230 with HC705 inside
But if you are not interested in building one on your own and want to spend a little bit more money to get a working EIS/ELV Tester, then this is a site that has been confirmed working by some of our mb friends:https://www.eobdtool.co.uk/wholesale/xhorse-elv-emulator.html (xhorse elv adapter); https://www.eobdtool.co.uk/wholesale/vvdi-mb-nec-elv-adaptor.html (elv adapter);https://www.eobdtool.co.uk/wholesale/mb-eis-elv-test-line.html  (eis/elv test cable)
... I wouldn't recommend other sites, although they may work, problem is that they have not been confirmed working yet.Functions of EIS/ELV adapter at eobdtool has been tested for years (many discussion in forums).
